• Solid exterior paint
• Chrome front bumper
• Dark argent air dam
• Molded grille painted argent
• Single rectangular halogen headlamps
• Daytime running lamps
• Cargo area lamp
• Dual black break-a-way mirrors
• Solar-Ray tinted glass (all windows)
• Intermittent windshield wiper system
• Cheyenne badge on B-pillar
• Removable tailgate
• Insulation under dash & floor covering

• 3-passenger bench seat w/folding backrest
• Scotchgard Fabric Protector on all cloth & carpet surfaces
• Color-keyed rubber floor mat
• Simulated leather steering wheel
• Key-in-ignition warning buzzer
• Heater/defogger w/side window defoggers
• ETR AM/FM stereo-inc: seek-forward/reverse, digital clock, 4 speakers
• Glove box w/latched door
• Dual dash cupholders
• Dual covered power points
• Cigarette lighter
• Molded plastic door trim panels w/dual integral armrests/map pockets
• Color-keyed cloth headliner
• Dual color-keyed padded cloth sunshades w/driver storage strap, passenger mirror
• Passenger assist handle
• Lighting-inc: dome, reading, ashtray, glove-box, delayed entry feature, underhood
• Dual coat hooks

• Four-wheel anti-lock brake system
• Driver air bag
• Manual lap/shoulder safety belts, outboard seat positions
• Front outboard shoulder belt height adjusters
• Manual lap safety belts, center seat position
• Energy-absorbing steering column/instrument panel
• Head restraints, front seat
• Daytime running lamps
• Side door guard beams
• Single note horn

4.3L (262) SFI V6 (VORTEC) ENGINE

• (STD)

• AM/FM radio
• Cassette
• Power steering
• ABS brakes
• Front anti-roll bar
• Bumpers: chrome
• Front reading lights
• Illuminated entry
• Passenger vanity mirror
• Tachometer
• Voltmeter
• Variably intermittent wipers

• Mileage
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 22
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 100
• Maximum Alternator Watts: 1200
• Cooling System
• Total Cooling System Capacity (qts): 12.8
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3150
• Gross Axle Wt Rating - Rear (lbs): 3686
• Curb Weight - Front (lbs): 2231
• Curb Weight - Rear (lbs): 1610
• Gross Vehicle Weight Rating Cap (lbs): 6100
• Gross Combined Wt Rating (lbs): 6500
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 2000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 400
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 2000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1000
• Suspension
• Suspension Type - Front: Indep Coil Spring
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 3200
• Spring Capacity - Rear (lbs): 3750
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3150
• Axle Capacity - Rear (lbs): 3750
• Axle Ratio (:1) - Rear: 3.08
• Shock Absorber Diameter - Front (mm): 25
• Shock Absorber Diameter - Rear (mm): 25
• Stabilizer Bar Diameter - Front (in): 1.25
• Brakes
• Brake Type: Power
• Brake ABS System: Four Wheel
• Disc - Front (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 11.57 x 1.25
• Drum - Rear (Yes or ): Yes
• Rear Drum Diam x Width (in): 10.0 x 2.25
• Tires
• Front Tire Order Code: XFL
• Rear Tire Order Code: YFL
• Spare Tire Order Code: ZFL
• Front Tire Size: P235/75R15
• Rear Tire Size: P235/75R15
• Spare Tire Size: P235/75R15
• Front Tire Capacity (lbs): 1763
• Rear Tire Capacity (lbs): 1843
• Spare Tire Capacity (lbs): 1843
• Revolutions/Mile @ 45 mph - Front: 722
• Revolutions/Mile @ 45 mph - Rear: 722
• Revolutions/Mile @ 45 mph - Spare: 722
• Wheels
• Front Wheel Size (in): 15 x 7
• Rear Wheel Size (in): 15 x 7
• Spare Wheel Size (in): 15 x 7
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Power
• Steering Ratio (:1), On Center: 16.5
• Steering Ratio (:1), At Lock: 15.6
• Turning Diameter - Curb to Curb (ft): 38.8
• Turning Diameter - Wall to Wall (ft): 44.2
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 25
• Fuel Tank Location: Inboard LH Frame
• Exterior Dimensions
• Wheelbase (in): 117.5
• Length, Overall w/o rear bumper (in): 194.5
• Width, Max w/o mirrors (in): 77.1
• Height, Overall (in): 70.4
• Overhang, Front (in): 35.4
• Overhang, Rear w/o bumper (in): 47.6
• Front Bumper to Back of Cab (in): 110.0
• Cab to Axle (in): 41.9
• Ground to Top of Load Floor (in): 29.0
• Frame Width, Rear (in): 36.7
• Ground Clearance, Front (in): 7.0
• Ground Clearance, Rear (in): 8.4
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.7
• Cargo Box Width @ Top, Rear (in): 49.1
• Cargo Box Width @ Floor (in): 49.1
• Cargo Box (Area) Height (in): 19.2
• Tailgate Width (in): 50.9
• Cargo Volume (ft³): 42.1
• Interior Dimensions
• Passenger Capacity: 3
• Front Head Room (in): 39.9
• Front Leg Room (in): 41.7
• Front Shoulder Room (in): 65.4
• Front Hip Room (in): 60.0
• Summary
• Vehicle Name: Chevrolet C/K 1500
• Body Style: Reg Cab 6.5' Sportside
• Body Code: E62
